Phoenix 20Amps Digital PWM solar charge controller - 12V/24V Auto Charge Control

Phoenix 20Amps Digital PWM solar charge controller - 12V/24V Auto Charge Control

• 20Amps Digital MPPT solar charge controller
• PWM Control
• 12v/24V Auto
• Microcontroller digital accuracy self test
• Multistage charging technology
• Load disconnection depending on LVD

• Automatic load reconnection
• Temperature Compensation

• Common positive grounding on one terminal
• Integrated data logger(optional)

• Night light and morning light function
• Integrated self test
• Automatic detection of voltage
• 24months Warranty

• Four-stage PWM charging mode.
• Preset charging parameters for three battery types.
• Detecting mode for battery voltage level is adjustable.
• Charging and discharging parameters are adjustable.
• Temperature compensation is applied.
• Various controlling mode for load.
• Optional communication function.
• Protection against reverse connected solar panel and input over-current.
• Protection against under-voltage, over-voltage, reverses connection and reverse discharge of battery.
• Protection against over-current of load.
• Protection against internal over-heat.

Technical data for 10Amp Phoenix Charge Control:
